48-7009-E 5-51
*4: Time unit setting (H/MP)
Set “time unit” and “step transfer condition (time countdown condition)” of a step.
Setting range Initial value: 0: Step time (hour: minute)
0: Step time (hour: minute)
1: Soak time 1 (hour: minute)
2: Soak time 2 (hour: minute)
3: Step time (minute: second)
4: Soak time 1 (minute: second)
5: Soak time 2 (minute: second)
Note Regarding meanings of “step,” “soak 1” and “soak 2”
“Step time”:
The step proceeds in accordance with a set step time (SET 22 tIM*) regardless
statuses of PV or SV. Therefore, a step proceeds to the next one when set time
elapses.
“Soak time 1”: Time is count down if a PV falls within the set WAIT range even once. A step
proceeds to the next one when set time elapses. Judgment is made with a set PV
even if a ramp is set.
“Soak time 2”: Time is count down only within a set WAIT range.
For details, see “Complementary explanation of the program run” in Section 5.5.7 (P5-61 and 62).
*5: WAIT range setting (WAIt)
Set “range for a PV value” when using the “soak time 1 or 2” function.
Setting range Initial value: 2
(During temperature input)
Soak time 1: 0 to 999 (0.0 to 999.9)

C
Soak time 2: 0 to 999 (0.0 to 999.9)

C
(During analog input)
Soak time 1: 0 to 9999 (digit)
Soak time 2: 0 to 9999 (digit)
Note Complementary to the WAIT range setting
The operation for the soak time 2 (H/MP

2) is the same as that for the soak time 1 in the WAIT
range setting (WAIt

0).
For details, see “Complementary explanation of the program run” in Section 5.5.7 (P5-61 and 62).
