48-7009-E 5-59
< Operation list table (2/3) >
INDEX Screen
Key operation
Behavior
Run status Type Operation method
⑤ Step time
monitor Before run MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To the program run start/stop screen
FU1-5 Depression Follows the function key setting.
 Prolonged press of 2 seconds Run start
 Prolonged press of 2 seconds No action

Depression No action

Depression No action
⑥ Run in process MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To the program run start/stop screen
FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds No action
 Prolonged press of 2 seconds No action
 Depression Setting: Remaining time increased
 Depression Setting: Remaining time decreased
⑦ Run end MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To the program run start/stop screen
FU1-5 Depression Follows the function key setting.
 Prolonged press of 2 seconds No action

Prolonged press of 2 seconds Run stop *4

Depression No action
 Depression No action
⑧ Program run
start/stop
screen Before run MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To the timer 1 monitor screen *1
FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds Run start
 Prolonged press of 2 seconds No action
 Depression No action

Depression No action
⑨ Run in process MODE Depression To the timer 1 monitor screen *1
FU1-5 Depression Follows the function key setting.
 Prolonged press of 2 seconds Step feed *3

Prolonged press of 2 seconds Run stop *4

Depression Run restart *2

Depression In pause
*2
⑩ Run end MODE Depression To the timer 1 monitor screen *1
FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds No action

Prolonged press of 2 seconds Run stop *4
 Depression No action
 Depression No action
Note *1: The timer monitor only displays the timer to be used. Timers unset are not displayed.
*2: This key operation is ineffective if “pause” is set for the FUNC key or DI.
*3: This key operation is ineffective if “step feed” is set for the FUNC key or DI.
*4: This key operation is ineffective if “start/stop” is set for the FUNC key or DI.
