48-7009-E 6-62
6.8 Timer function setting
■ Timer function setting
SEt14
tIME1
to
SEt16
tIME3
Setting content Initial value
1
tMF1
to
tMF3
1 Auto start
1
2 Manual start
3 SV start
4 DI 1 start (settable when an option existent)
5 DI 2 start (settable when an option existent)
6 DI 3 start (settable when an option existent)
7 DI 4 start (settable when an option existent)
8 Event 1 start
9 Event 2 start
10 Event 3 start (settable when an option existent)
11 Event 4 start (settable when an option existent)
12 Event 5 start (settable when an option existent)
13 Event 6 start (settable when an option existent)
14 Event 7 start (settable when an option existent)
15 Step Start (during program mode) 3
16 Soak Start (during program mode) 3
Set functions of timers 1 to 3.
Note Setting the control modes to TIME 1 to 3 or setting the target connection setting (o1F to o7F) to 5 to 16 is required for
operating timers.
Note Triggers for starting timers are DI, FUNC key and / key, in this order from higher priority.
For details of the timer setting, see section “5.4.5 Timer function” on pages 5-32 to 37.
When the SV start is set, set the start SV permissible range setting.
■ Unit setting
SEt14
tIME1
to
SEt16
tIME3
Setting content Initial value
2
H/M1
to
H/M3
1 Hour/minute
1
2 Minute/second
Set the unit of time for timers 1 to 3.
