48-7009-E 7-15
7.5.3 Input 2 setting mode (SET 02)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Input type INP2
16: 0 - 1 VDC
17: 0 - 5 VDC
18: 1 - 5 VDC
19: 0 - 10 VDC
20: 4 - 20 mADC
18 None
Scaling upper limit FSH2
FSL 2 to SV setting range upper
limit
1200
Scaling lower limit FSL2
SV setting range lower limit to
FSH 2
0
PV compensation
gain
PVG2 0.500 to 2.000 1.000 Times
PV compensation
zero
PVS2 -999 to 999 0 Digit
PV filter PdF2 0.0 to 99.9 0.0 Second
Local/remote
switchover
LR
0: Local
1: Remote 1
(Scaled with SLL , SLH )
2: Remote 2
(Scaled with FSL 2, FSH 2)
0 None
7.5.4 Key function setting mode (SET 03)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Function key 1
function
Function key 2
function
Function key 3
function
Function key 4
function
Function key 5
function
FU1
to
FU5
*0: No function
*1: Digit shift
*2: Control mode (MD)/control
stop (RDY)
*3: AT start/AT stop
*4: Timer start/stop
*5: Screen reverse feed
*6: ENT
*7: Bank switchover
*8: AUTO/MANUAL
*9: SV/MV screen switchover
*A: Constant value run mode/
Program mode switchover *1
*B: Step feed *1
*C: Pause *1
*d: SET 22 call-up function *1
0.0
None
0*: None
1*: Pressing time of 1 second
2*: Pressing time of 2 seconds
3*: Pressing time of 3 seconds
4*: Pressing time of 4 seconds
5*: Pressing time of 5 seconds
Second
Key lock LoC
0: Lock OFF
1: Lock all
2: Lock of run mode
3: Lock of other than run mode
4: Lock all (only during a run) *1
5: Lock of run mode (only during
a run) *1
6: Lock of other than run mode
(only during a run) *1
7: Lock of parameter mode (only
during a run) *1
0 None
*1: Selectable only on Ver3.xx or later
