48-7009-E 7-14
7.5.2 Input 1 setting mode (SET 01)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Input type INP1
0: K thermocouple
1: J thermocouple
2: T thermocouple
3: E thermocouple
4: R thermocouple
5: S thermocouple
6: B thermocouple
7: N thermocouple
8: U thermocouple
9: L thermocouple
10: WRe5-26
11: PR40-20
12: PLII
13: Pt100
14: JPt100
15: 0 - 10 mVDC
16: 0 - 1 VDC
17: 0 - 5 VDC
18: 1 - 5 VDC
19: 0 - 10 VDC
20: 4 - 20 mADC
0
Scaling upper limit FSH1 FSL1 to 29999 10000 Digit
Scaling lower limit FSL1 -19999 to FSH1 -10000 Digit
PV compensation
function setting
PVF1
0: PV gain zero point
compensation
1: PV X-Y2 point compensation
0
PV compensation
gain
PVG1 0.500 to 2.000 1.000 Times
PV compensation
zero
PVS1
Temperature: -999.9 to 999.9
-999 to 999
Analog: -9999 to 9999
0

C
Digit
PV before-
compensation lower
limit value setting
PX1
Setting range:
Setting range lower limit to (PX2 -
1

C)
Setting range lower limit to (PX2 -
10 digits)
Setting unit: 1

C or 0.1

C; 1 digit
0
PV before-
compensation upper
limit value setting
PX2
Setting range:
(PX1

1

C) to setting range
upper limit
(PX1

10 digits) to setting range
upper limit
Setting unit: 1

C or 0.1

C; 1 digit
1200
PV after-
compensation lower
limit value setting
PY1
Setting range:
Setting range lower limit to (PY2 -
1

C)
Setting range lower limit to (PY2 -
10 digits)
Setting unit: 1

C or 0.1

C; 1 digit
0
PV after-
compensation upper
limit value setting
PY2
Setting range:
(PY1

1

C) to setting range
upper limit
(PY1

10 digits) to setting range
upper limit
Setting unit: 1

C or 0.1

C; 1 digit
1200
Input filter PdF1 0.0 to 99.9 0.0 second
Decimal point
position
dP1
Temperature: 0/0.0
Analog: 0/0.0/0.00
0.000/0.0000
0

C
Digit
Unit of temperature  C,  F  C
Note The characters (PVF1, PX1, PX2, PY1 and PY2) are selectable only on Ver3.xx or later.
