7.5.9 DI setting mode (SET 13)
Setting data
Character
Setting (monitor) value
Initial value
Unit
Setting
value
Blind
DI function
dIF
※, ★, ☆ and ◎
◎: DI 1 setting
☆: DI 2 setting
★: DI 3 setting
※: DI 4 setting
0000
None
DI content (function) assignment table
Active
0
None
None
1
Bank switchover
Bank switcher
2
MD
READY
3
AUTO
MANUAL
4
Reverse operation
Forward operation
5
AT stop
AT start
6
Timer stop
Timer start
7
Constant value run mode
Program run mode *1
8
Step feed *1
9
Pause *1
A
Interlock *1
*1: Selectable only on Ver3.xx or later.
Setting data
Character
Setting (monitor) value
Initial value
Unit
Setting
value
Blind
DI polarity
dIP
※, ★, ☆ and ◎
◎: DI 1 setting
☆: DI 2 setting
★: DI 3 setting
※: DI 4 setting
Function assignment
0: Close active
1: Open active
0000
None
