48-7009-E 6-50
■ Event function 1/upper and lower limits/sensitivity/delay timer settings
SEt05
oUt1
to
SEt11
oUt7
Setting content Initial value
2
E1F1
to
E7F1
Function
000
**0 None
**1 Deviation upper and lower limits
**2 Deviation upper limit
**3 Deviation lower limit
**4 Deviation range
**5 Absolute value upper and lower limits
**6 Absolute value upper limit
**7 Absolute value lower limit
**8 Absolute value range
Add-on function
*0* None
*1* Hold
*2* Standby
*3* Delay
*4* Hold + standby
*5* Hold + delay
*6* Standby + delay
*7* Hold + standby + delay
Control mode interlocking function
0** All modes
1** RUN/MAN mode only
2** RUN mode only
3
E1H
to
E7H
Thermocouple/resistance temperature detector input
-1999.9 to 2999.9 (

C)
-1999 to 2999 (

C) 0
Voltage/current input
-19999 to 29999 (digit)
4
E1L
to
E7L
Thermocouple/resistance temperature detector input
-1999.9 to 2999.9 (

C)
-1999 to 2999 (  C) 0
Voltage/current input
-19999 to 29999 (digit)
5
E1C
to
E7C
Thermocouple/resistance temperature detector input
0.0 to 999.9 (

C)
0 to 999 (

C) 0
Voltage/current input
0 to 9999 (digit)
6
E1t
to
E7t
0 to 9999 (seconds) 0
Event function 1/event upper and lower limits/event sensitivity/event delay timer is set.
Event function 1 is a function that compares PV to the event setting value, and that, if set conditions are met, signals are output
(ON/OFF) from the outputs 1 to 7 assigned for the event output.
This function is effective for alarm of PV, and start/stop of other systems.
This function can be used when the target connection for the outputs 1 to 7 are set for the event output.
For the operation range and each setting value of the event function 1, see the event function 1 operation on page 6-49.
