48-7009-E 7-29
7.5.12 Initial setting mode (SET 18)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Password cancel
screen PASS
(Blinking)
0000 to 9999
Change the 4-digit value and press the
MODE key for release.
0000 None
PV normal state
display color
NdSP 0: Green 0
None
PV auto color display
low
AdSL 1: Red 1
PV auto color display
middle
AdSM 2: Orange 0
PV auto color display
high
AdSH 3: Auto (only NdSP) 2
PV display color
switchover
PVC
Thermocouple/resistance temperature
detector input
0.0 to 999.9 (
 C)
0 to 999 (

C)
1

C
Voltage/current input
0 to 9999 (digit)
Digit
PV at-event display
color
E1dSP 0: Green 2
None
PV at-abnormality
display color
E2dSP 1: Red 1
CT at-abnormality
display color
E3dSP 2: Orange 1
Loop at-abnormality
display color
E4dSP 0
Blind function
effective/ineffective
bLd
0: Function existent
1: Function nonexixtent
0 None
Setting value backup bKUP
Backup begins by pressing the FUNC
key for 2 seconds.
“SAVE” is displayed during backup;
terminated light indicates completed
backup. None
Setting value
initialization
RESEt
0: At-factory-shipment setting
1: Backup setting
Initialization begins by pressing the
FUNC key for 2 seconds.
“INIt” is displayed during initialization:
terminated light indicates completed
initialization.
0 None
Password setting
PASS
(Lighting)
0000 to 9999
After a 4-digit numerical value is
changed, pressing the FUNC key for 2
seconds confirms or cancels the
change.
0000 None
7.5.13 Priority screen setting mode (SET 19)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Priority screen 01 PRI01
Parameters for
SET 01 to SET 17
OFF
None
Priority screen 02 PRI02 OFF
Priority screen 03 PRI03 OFF
Priority screen 04 PRI04 OFF
Priority screen 05 PRI05 OFF
Priority screen 06 PRI06 OFF
Priority screen 07 PRI07 OFF
Priority screen 08 PRI08 OFF
Priority screen 09 PRI09 OFF
Priority screen 10 PRI10 OFF
Priority screen 11 PRI11 OFF
Priority screen 12 PRI12 OFF
Priority screen 13 PRI13 OFF
Priority screen 14 PRI14 OFF
Priority screen 15 PRI15 OFF
Priority screen 16 PRI16 OFF
