48-7009-E
7-20
7.5.6 OUT 1 and 2 setting modes (SET 05 and 06) (1/3)
Setting data
Character
Setting (monitor) value
Initial value
Unit
Setting
value
Blind
Target connection
o1F
o2F
0: Primary output
1: Secondary output
2: Event output
3: RUN output
4: RDY output
5: Timer 1 output
6: Timer 1 during-on-delay output
7: Timer 1 during-off-delay output
8: Timer 1 during-[on + off]-delay
output
9: Timer 2 output
10: Timer 2 during-on-delay
output
11: Timer 2 during-off-delay
output
12: Timer 2 during-[on + off]-delay
output
13. Timer 3 output
14: Timer 3 during-on-delay
output
15: Timer 3 during-off-delay
output
16: Timer 3 during-[on + off]-delay
output
17: Transmission output
18: End output *1
OUT1: 0
OUT2: 2
None
Event function 1
E1F1
E2F1
Function
**0: None
**1: Deviation upper and lower
limits
**2: Deviation upper limit
**3: Deviation lower limit
**4: Deviation range
**5: Absolute value upper and
lower limits
**6: Absolute value upper limit
**7: Absolute value lower limit
**8: Absolute value range
Add-on function
*0*: None
*1*: Hold
*2*: Standby
*3*: Delay
*4*: Hold + standby
*5*: Hold + delay
*6*: Standby + delay
*7*: Hold + standby + delay
Control mode interlocking function
0**: All modes
1**: RUN/MAN mode only
2**: RUN mode only
000
None
Event upper limit
E1H
E2H
Temperature: -1999.9 to 2999.9
-19999 to 2999
Note that, for thermocouples R, S
and B, the value of WRe 5-26 or
PR 40-20 is -1999 to 9999.
Analog: -19999 to 29999
0
C
Digit
*1: Selectable only on Ver3.xx or later.
