48-7009-E 7-3
d) 0 - 10 VDC
I)
Measurement accuracy
In standard environment conditions (23 ± 10 °C), ± 0.3 % ± 1 digit of FS
II) Input resistance
1 M

or larger
III) When disconnected
“ ” (underscale) displayed
Control output: Operating amount limiter lower limit
e) 0 - 10 mVDC
I)
Measurement accuracy
In standard environment conditions (23 ± 10 °C), ± 0.5 % ± 1 digit of FS
II) Input resistance
1 M

or larger
III) When disconnected
“ ” (underscale) displayed
Control output: Operating amount limiter lower limit
f) Current input 4 - 20 mADC
I)
Measurement accuracy
In standard environment conditions (23 ± 10 °C), ± 0.3 % ± 1 digit of FS
II) Input resistance
Approx. 250

III) When disconnected
“ ” (underscale) displayed
Control output: Operating amount limiter lower limit
9) Isolation
Isolated from power circuit and non-isolated from CPU circuit
10) Connection method
Terminal block
Table 1 Measurement range and indicator resolution
Input type Standards
Measurement/measurement
range
Indicator resolution
Thermocouple
K JIS C 1602-1995 -200.0 to +1372.0 1  C / 0.1  C
J JIS C 1602-1995 -200.0 to +1200.0 1

C / 0.1

C
T JIS C 1602-1995 -200.0 to +400.0 1

C / 0.1

C
E JIS C 1602-1995 -200.0 to +1000.0 1

C / 0.1

C
R JIS C 1602-1995 -50 to +1768 1

C
S JIS C 1602-1995 -50 to +1768 1  C
B JIS C 1602-1995 0 to 1800 1

C
N JIS C 1602-1995 -200.0 to +1300.0 1

C / 0.1

C
U DIN -200.0 to +400.0 1

C / 0.1

C
L DIN -200.0 to +900.0 1

C / 0.1

C
WRe5-26 ASTM 0 to 2300 1

C
PR40-20 ASTM 0 to 1880 1  C
PLII ASTM 0.0 to 1390.0 1  C / 0.1  C
Resistance
temperature detector Pt100

JIS C 1604-1997 -200.0 to +850.0 1

C / 0.1

C
J Pt100

JIS C 1604-1997 -200.0 to +510.0 1

C / 0.1

C
Voltage
0 - 1 VDC
-19999 to +29999
Display range of 20000
or less
Random change of
decimal point position
allowed
0 - 5 VDC
1 - 5 VDC
0 - 10 VDC
0 - 10 mVDC
Current 4 - 20 mADC
When the measurement range is set to be smaller than the maximum range for the voltage or current input, display is possible up
to -2 % from the lower limit and +12 % from the upper limit in the setting that allows the input of 0 V.
Display is possible up to -12 % from the lower limit and +12 % from the upper limit for DC 1 to 5 and DC 4 to 20 mA.
