CLS200 Series User’s Guide Chapter 4: Setup
Doc.# 0600-3050-2000 Watlow Anafaze 83
Input Type
Specify the type of input sensor used on this loop:
• Thermocouple type J, K, T, S, R, B or E.
• RTD 1 or RTD 2.
• Linear input.
• Skip (an input type available for unused loops).
Alarms are not detected, and the scanning display
does not show loops that are set to SKIP.
• Pulse input (available only for loop 5 on CLS204, loop
9 on CLS208 or loop 17 on CLS216).
Selectable values: See Table 4.6.
Table 4.6 CLS200 Input Types and Ranges
Input
Type
Input Range
J T/C -350 to +1,400 ° F (-212 to +760 ° C)
K T/C -450 to +2,500 ° F (-268 to +1,371 ° C)
T T/C -450 to +750 ° F (-268 to +399 ° C)
S T/C 0 to +3,200 ° F (-18 to +1,760 ° C)
R T/C 0 to +3,210 ° F (-18 to +1,766 ° C)
B T/C +150 to 3,200 ° F (+66 to 1,760 ° C)
E T/C +150 to 3,200 ° F (+66 to 1,760 ° C)
RTD1 -148.0 to +572.0 ° F (-100.0 to +275.0 ° C)
RTD2 -184 to +1,544 ° F (-120 to +840 ° C)
PULSE 0 to 2 kHz
SKIP Loop not used.
LINEAR See Linear Scaling Parameters on page 86.
ALARM
01 INPUT
TYPE ? J T/C
