Chapter 11: Specifications CLS200 Series User’s Guide
208 Watlow Anafaze Doc.# 0600-3050-2000
Dual DAC Inputs
The Dual DAC accepts an open-collector signal from the
CLS200 controller and the power from an external power
supply. See Table 11.31.
Table 11.31 Dual DAC Power Requirements
Dual DAC Analog Outputs
Table 11.32 Dual DAC Specifications by Output
Range
Parameter Description
Voltage 12 to 24V Î (dc)
Current 100 mA @ 15V Î (dc)
Version 4-20 mA 0-5 V 0-10 V Units
Gain Accuracy ± 6 ± 6 ± 6 %
Output Offset ± 0.75 ± 0.75 ± 0.75
% of full scale
range
Ripple 1.6 1.6 1.6
% of full scale
range
Time Constant 2 2 2 seconds
Maximum Current Output 20 10 10 mA dc
Load Resistance (12V) 250 maximum 500 minimum 1000 minimum Ω
Load Resistance (24V) 850 maximum n/a n/a Ω
