Retransmit Process Variable
Enter the number of the loop that provides the process
variable for the retransmit calculation.
If you set this parameter NONE and press NO, the controller
skips to the COOL OUTPUT RETRANS PV screen. The COOL
parameter is set up the same way as the HEAT parameter.
Selectable values: Any loop or NONE.
Minimum Input
Enter the lowest value of the process variable to be retrans-
mitted. This value is expressed in the same engineering
units as the input loop.
If the process variable falls below the minimum, the output
will stay at the minimum value.
Selectable values: Any value in the input loop’s range.
Minimum Output
Enter the output value (0 to 100%) that corresponds to the
minimum input.
Selectable values: 0 to 100%
If you select a minimum output value other than 0%, the
output will never drop below MIN OUT, even if the process
variable drops below the MIN INP that you specified.
Maximum Input
Enter the highest value of the process variable to be re-
transmitted. This value is expressed in the same engineer-
ing units as the input loop.
If the process variable goes above the maximum, the output
will stay at the maximum value.
Selectable values: Any value in the input loop’s range.
ALARM
02 HEAT OUTPUT
RETRANS PV? 02
ALARM
02 HEAT RETRANS
MIN INP? 1000
ALARM
02 HEAT RETRANS
MIN OUT%? 0%
ALARM
02 HEAT RETRANS
MAX INP? 10000
