Chapter 2: Installation CLS200 Series User’s Guide
42 Watlow Anafaze Doc.# 0600-3050-2000
Table 2.7 TB50 Connections for CLS216
1
The indicated outputs are dedicated for control when enabled in
the loop setup. If one or both of a loop’s outputs are disabled, the
corresponding digital outputs become available for alarms or
ramp/soak events.
2
If you install a Watlow Anafaze Serial DAC, the controller uses
digital output 34 (terminal 10) for a clock line. You cannot use out-
put 34 for anything else when you have a Serial DAC installed.
Terminal Function
CLS216
Control Output 1
Terminal Function
CLS216
Control Output 1
1
+5V Î (dc) 2 +5V Î (dc)
3
CTRL COM 4 CTRL COM
5
Not Used 6 Watchdog Timer
7
Pulse Input 8 Global Alarm
9
Output 1 Loop 1 heat 10
Output 34 2 Pulse loop cool
11
Output 2 Loop 2 heat 12 Output 33 Loop 16 cool
13
Output 3 Loop 3 heat 14 Output 32 Loop 15 cool
15
Output 4 Loop 4 heat 16 Output 31 Loop 14 cool
17
Output 5 Loop 5 heat 18 Output 30 Loop 13 cool
19
Output 6 Loop 6 heat 20 Output 29 Loop 12 cool
21
Output 7 Loop 7 heat 22 Output 28 Loop 11 cool
23
Output 8 Loop 8 heat 24 Output 27 Loop 10 cool
25
Output 9 Loop 9 heat 26 Output 26 Loop 9 cool
27
Output 10 Loop 10 heat 28 Output 25 Loop 8 cool
29
Output 11 Loop 11 heat 30 Output 24 Loop 7 cool
31
Output 12 Loop 12 heat 32 Output 23 Loop 6 cool
33
Output 13 Loop 13 heat 34 Output 22 Loop 5 cool
35
Output 14 Loop 14 heat 36 Output 21 Loop 4 cool
37
Output 15 Loop 15 heat 38 Output 20 Loop 3 cool
39
Output 16 Loop 16 heat 40 Output 19 Loop 2 cool
41
Output 17 Pulse loop heat 42 Output 18 Loop 1 cool
43
Input 1 44 Input 2
45
Input 3 46 Input 4
47
Input 5 48 Input 6
49
Input 7 50 Input 8
