Chapter 2: Installation CLS200 Series User’s Guide
40 Watlow Anafaze Doc.# 0600-3050-2000
TB18 Connections (CLS204 and CLS208 Only)
Table 2.5 TB18 Connections
1
The indicated outputs are dedicated for control when enabled in
the loop setup. If one or both of a loop’s outputs are disabled, the
corresponding digital outputs become available for alarms or
ramp/soak events.
2
If you install a Watlow Anafaze Serial DAC, the CLS200 series
controller uses digital output 34 for a clock line. You cannot use
output 34 for anything else when you have a Serial DAC installed.
Control Output 1
Terminal Function CLS204 CLS208
1 +5V Î (dc)
2 CTRL COM
3 Watchdog timer
4 Global alarm
5 Output 1 Loop 1 heat Loop 1 heat
6 Output 2 Loop 2 heat Loop 2 heat
7 Output 3 Loop 3 heat Loop 3 heat
8 Output 4 Loop 4 heat Loop 4 heat
9 Output 5 Pulse loop heat Loop 5 heat
10 Output 6 Loop 1 cool Loop 6 heat
11 Output 7 Loop 2 cool Loop 7 heat
12 Output 8 Loop 3 cool Loop 8 heat
13 Output 9 Loop 4 cool Pulse loop heat
14 Output 10 Pulse loop cool Loop 1 cool
15 Output 34 2 Serial DAC clock Serial DAC clock
16 Input 1
17 Input 2
18 Input 3/Pulse input
