Chapter 7: Ramp/Soak CLS200 Series User’s Guide
142 Watlow Anafaze Doc.# 0600-3050-2000
Edit Segment Triggers
Each segment may have up to two triggers (digital inputs).
Both triggers must be true in order for the segment to run.
If a trigger is not true, the profile goes into the trigger wait
state.
Press
YES to edit triggers for the current segment, or NO
to advance to the SEGMENT TOLERANCE parameter.
Trigger Input Number
Assign a digital input to a segment trigger. You can assign
any digital input to any trigger. You can also assign the
same digital input as a trigger in more than one segment
and more than one profile.
This parameter appears only if you answered YES to EDIT
SEG TRGGRS?
Selectable values: Any digital input from 1 to 8, or NONE
(disable trigger).
When you are done editing segment triggers, press BACK
to return to EDIT SEG TRGGRS.
Trigger Active State
Choose the state that will satisfy the trigger condition. A
trigger input is ON when pulled low by an external device.
A trigger input is OFF when the digital input is high.
This parameter appears only if you answered YES to EDIT
SEG TRGGRS?
Selectable values: OFF or ON.
ALARM
A SEGMENT 15
EDIT SEG TRGGRS?
ALARM
A SEG 15 TRIG 1
INPUT NR ? NONE
ALARM
A SEG01 TR1 DIO8
ACTIVE STATE?OFF
