CLS200 Series User’s Guide Chapter 9:Troubleshooting and Reconfiguring
Doc.# 0600-3050-2000 Watlow Anafaze 185
Table 9.13 Resistor Locations for CLS216
Current Inputs
CLS216 Voltage Inputs
For each voltage input on a CLS216 controller, you must in-
stall two resistors. The resistance must be correct for the
expected input range. Install the resistors in the listed lo-
cations.
Table 9.14 Resistor Values for CLS216
Voltage Inputs
Resistor tolerance: ± 0.1%
Loop
Resistor
Location
RD
Loop
Resistor
Location
RD
1 R42 9 R41
2 R40 10 R39
3 R38 11 R37
4 R36 12 R35
5 R34 13 R33
6 R32 14 R31
7 R30 15 R29
8 R28 16 R27
Resistor Values
Input Range RC RD
0 to 100mV Î (dc) 499 Ω 750 Ω
0 to 500mV Î (dc) 5.49 k Ω 750 Ω
0 to 1V Î (dc) 6.91 k Ω 442.0 Ω
0 to 5V Î (dc) 39.2 k Ω 475.0 Ω
0 to 10V Î (dc) 49.9 k Ω 301.0 Ω
0 to 12V Î (dc) 84.5 k Ω 422.0 Ω
