CLS200 Series User’s Guide Chapter 11: Specifications
Doc.# 0600-3050-2000 Watlow Anafaze 201
Table 11.12 Pulse Inputs
Table 11.13 Thermocouple Range and
Resolution
* True for 10% to 100% of span except type B, which is specified for 800˚ F to 3200˚ F.
Table 11.14 RTD Range and Resolution
Parameter Description
Number 1
Frequency Range 0 to 2,000 Hz
Input Voltage Protection Diodes to supply and common
Voltage Levels
<1.3V: Low
>3.7V: High (TTL)
Maximum Switch Resistance to
Pull Input Low
2 k Ω
Minimum Switch Off Resistance 30 k Ω
Thermocouple
Type
Range
in °F
Range
in °C
Accuracy* at
25°C Ambient
Accuracy* at
0 to 50°C
Ambient
°F °C °F °C
J -350 to 1,400 -212 to 760 ±2.2 ±1.2 ±3.3 ±1.8
K -450 to 2,500 -268 to 1371 ±2.4 ±1.3 ±3.8 ±2.1
T -450 to 750 -268 to 399 ±2.9 ±1.6 ±5.8 ±3.2
S 0 to 3,200 -18 to 1,760 ±5.0 ±2.8 ±8.8 ±4.9
R 0 to 3,210 -18 to 1,766 ±5.0 ±2.8 ±8.8 ±4.9
B 150 to 3,200 66 to 1,760 ±7.2 ±4.0 ±22.1 ±12.3
E -328 to 1,448 -200 to 787 ±1.8 ±1.0 ±2.9 ±1.6
Name
Range
in °F
Range
in °C
Resolution
in °C
Measurement
Temperature
in °C
Accuracy
at 25°C
Ambient
Accuracy at
0 to 50°C
Ambient
°F °C °F °C
RTD1
-148.0 to
527.0
-100.0 to
275.0
0.023
25 ±0.7 ±0.4 ±1.0 ±0.6
275 ±1.9 ±1.1 ±2.8 ±1.6
RTD2
-184 to
1544
-120 to 840 0.023
25 ±2.5 ±1.4 ±5.9 ±3.3
840 ±2.9 ±1.6 ±8.6 ±4.8
