Chapter 11: Specifications CLS200 Series User’s Guide
204 Watlow Anafaze Doc.# 0600-3050-2000
Table 11.19 5VО
О О О
(dc) Output (Power to Operate
Solid-State Relays)
Table 11.20 Reference Voltage Output (Power
to Operate Bridge Circuit Sensors)
Table 11.21 Processor Serial Interface
Table 11.22 Processor Power Requirements
Parameter Description
Voltage 5V Î (dc)
Maximum Current 350 mA
Parameter Description
Voltage 5V Î (dc)
Maximum Current 100 mA
Parameter Description
Type EIA/TIA-232 3-wire or EIA/TIA-485 4-wire
Isolation None
Baud Rate 2,400, 9,600 or 19,200 user selectable
Error Check BCC or CRC, user selectable
Number of Controllers
1 with EIA/TIA-232 communications; up to 32 with EIA/
TIA-485 communications, depending upon protocol
Protocol
Form of ANSI X3.28-1976 (D1, F1), compatible with Allen Bra-
dley PLC, full duplex or Modbus RTU
Parameter Description
Voltage 15 to 24V Î (dc) +/- 3V Î (dc)
Maximum Current 1 A
