CLS200 Series User’s Guide

Chapter 7: Ramp/Soak

Doc.# 0600-3050-2000

Watlow Anafaze

135

Table 7.1

Ramp/Soak Specifications

Number of possible profile

17

Number of times to repeat a profil

1 to 99 or

Continuous

Number of segments per profil

1 to 20

Number of triggers per segment

Up to 2

Type of triggers

On,

On Latched, Off,

Off Latched

Number of possible inputs for triggers

8

Number of events per segment

Up to 4

Number of possible outputs for events

(At least one of these outputs must be

used for control)

34
