CLS200 Series User’s Guide Chapter 4: Setup
Doc.# 0600-3050-2000 Watlow Anafaze 99
Setup Loop Alarms Menu
Use the SETUP LOOP ALARMS menu to set:
• High and low process and deviation alarm limits
• Alarm outputs
• Alarm/control behavior
• Alarm deadband
• Alarm delay
Table 4.13 shows the parameters available in the SETUP
LOOP ALARMS menu.
Table 4.13 Setup Loop Alarms
Parameter
Default
Value
HI PROC ALARM SETPT? 1000
HI PROC ALARM TYPE? OFF
HI PROC ALARM OUTPUT? NONE
DEV ALARM VALUE? 5
HI DEV ALARM TYPE? OFF
HI DEV ALARM OUTPUT? NONE
LO DEV ALARM TYPE? OFF
LO DEV ALARM OUTPUT? NONE
LO PROC ALARM SETPT? 0
LO PROC ALARM TYPE? OFF
LO PROC ALARM OUTPUT? NONE
ALARM DEADBAND? 2
ALARM DELAY? 0 SECONDS
ALARM
SETUP LOOP 01
ALARMS ?
