Chapter 7: Ramp/Soak CLS200 Series User’s Guide
144 Watlow Anafaze Doc.# 0600-3050-2000
If you enter a negative tolerance, the process goes out of tol-
erance when the process variable goes below the setpoint
minus the tolerance.
Selectable values: -99 to 99, or OFF (no tolerance limit).
See Setpoints and Tolerances for Various Input Types on
page 144.
Last Segment
Specify whether the current segment is the last one in the
profile.
Selectable values: NO or YES.
Repeat Cycles
Set the number of times you want a profile to repeat or cycle.
The profile returns to START mode after completing the
number of cycles specified here.
Selectable values: 1 to 99, or C (continuous cycling).
Setpoints and Tolerances for Various Input Types
Setpoints and tolerances are set in segments before the
profile is assigned to a particular loop. When the profile is
used with a loop, the INPUT TYPE and DISP FORMATS set-
tings are applied to the following parameters:
• Ready setpoint
• Segment setpoint
• Segment tolerance
Refer to Table 7.3 to determine how these parameters are
affected for the various INPUT TYPE and DISP FORMAT
settings.
ALARM
A SEGMENT 01
SEG TOLERNCE? OFF
ALARM
A SEGMENT 01
LAST SEGMENT? NO
ALARM
A REPEAT CYCLES
? 1
