CLS200 Series User’s Guide Chapter 2: Installation
Doc.# 0600-3050-2000 Watlow Anafaze 13
WARNING! To reduce the risk of fire or electric shock, in-
stall the CLS200 in a controlled environment,
relatively free of contaminants.
Recommended Tools
Use any of the following tools to cut a hole of the appropri-
ate size in the panel.
• Jigsaw and metal file, for stainless steel and heavy-
weight panel doors.
• Greenlee 1/8-DIN rectangular punch (Greenlee part
number 600-68), for most panel materials and thick-
nesses.
• Nibbler and metal file, for aluminum and lightweight
panel doors.
You will also need these tools:
• Phillips head screwdriver
• 1/8 in. (3 mm) flathead screwdriver for wiring
• Multimeter
Mounting the Controller
Mount the controller before you mount the terminal block
or do any wiring. The controller’s placement affects place-
ment and wiring considerations for the other components
of your system.
Ensure there is enough clearance for mounting brackets,
terminal blocks, and cable and wire connections; the con-
troller extends up to 7.0 inches (178 mm) behind the panel
face and the screw brackets extend 0.5 inch (13 mm) above
and below it. If using a straight SCSI cable, allow for an ad-
ditional 1.6 inches (41 mm) beyond the terminal block. If
using a right-angle SCSI cable, allow an additional 0.6 inch
(15 mm). (See Figure 2.2 and Figure 2.3.)
