Chapter 4: Setup CLS200 Series User’s Guide
74 Watlow Anafaze Doc.# 0600-3050-2000
Setup Global Parameters Menu
Table 4.1 shows the parameters available in this menu.
Table 4.1 Global Parameters
* The RAMP/SOAK TIME BASE parameter appears only if the ramp/soak
feature is installed.
Parameter Default Value
LOAD SETUP FROM JOB? 1
SAVE SETUP TO JOB? 1
JOB SELECT DIG INPUTS? NONE
JOB SEL DIG INS ACTIVE? LOW
OUTPUT OVERRIDE DIG INPUT? NONE
OVERRIDE DIG IN ACTIVE? LOW
STARTUP ALARM DELAY? 0 MINS
RAMP/SOAK TIME BASE? * HOURS/MINS
KEYBOARD LOCK STATUS? OFF
POWER UP OUTPUT STATUS? OFF
PROCESS POWER DIGIN? NONE
CONTROLLER ADDRESS? 1
COMMUNICATIONS BAUD RATE? 9600
COMMUNICATIONS PROTOCOL? ANA
COMMUNICATIONS ERR CHECK? BCC
AC LINE FREQ? 60 HERTZ
DIG OUT POLARITY ON ALARM? LOW
CLS200 [model no., fi mware rev.]
ALARM
SETUP GLOBAL
PARAMETERS
