CLS200 Series User’s Guide Chapter 4: Setup
Doc.# 0600-3050-2000 Watlow Anafaze 79
Selectable values: OFF or MEMORY.
Process Power Digital Input
To enable the thermocouple short detection feature, select
a digital input (1 to 8). Connect the specified input to a de-
vice that pulls the input low when the process power is on.
A short is indicated when the process power is on and the
temperature does not rise as expected.
If the controller determines that there is a thermocouple
short, it sets the loop to manual mode at the power level set
for the SENSOR FAIL HT OUTPUT or SENSOR FAIL CL
OUTPUT parameter in the SETUP LOOP OUTPUTS menu.
Selectable values: 1 to 8, or NONE.
Controller Address
Set the communications address for the controller. On an
EIA/TIA-485 communication loop, each controller must
have a unique address. Begin with address 1 for the first
controller and assign each subsequent controller the next
higher address.
Selectable values: 1 to 247. When using one controller
with Anasoft, select address 1. When using multiple con-
trollers with Anasoft, use consecutive addresses from 1 to
16 only.
ALARM
POWER UP OUTPUT
STATUS ? OFF
ALARM
PROCESS POWER
DIGIN ? NONE
ALARM
CONTROLLER
ADDRESS ? 1
