Doc.# 0600-3050-2000

Watlow Anafaze

107

Extruder Control

This chapter explains the additional features for the
CLS200 series controller equipped with Extruder Control
Firmware. Except for setup, default and control algorithm
differences described below, the Extruder Control Firm-
ware operates the same as the standard control firmware.

Setup Loop Outputs Menu

The SETUP LOOP OUTPUTS menu contains a parameter
with descriptors for the selections that are different than
those in the standard control firmware.

Cool Output Nonlinear Output Curve

Select linear or nonlinear output curves for the cool output.

Selectable Values: FAN, OIL or H2O. See Figure 5.1.

ALARM

SETUP LOOP 01
OUTPUTS ?

ALARM

01 COOL OUTPUT
FAN
