Chapter 11: Specifications CLS200 Series User’s Guide
202 Watlow Anafaze Doc.# 0600-3050-2000
Table 11.15 Input Resistance for Voltage Inputs
Table 11.16 Digital Inputs
Outputs
The controller directly accommodates switched dc and
open-collector outputs only. These outputs can be used to
control a wide variety of loads. They are typically used to
control SSRs or other power switching devices which in
turn control, for example, heaters. They may also be used
to signal another device of an alarm condition in the con-
troller.
Analog outputs may be accomplished by using Dual DAC or
Serial DAC modules in conjunction with one of the control
outputs.
An open-collector CPU watchdog output is also provided so
that an external device may monitor the CPU state.
Range Input Resistance
0 to 12V 85 k Ω
0 to 10V 50 k Ω
0 to 5V 40 k Ω
0 to 1V 7.4 k Ω
0 to 500mV 6.2 k Ω
0 to 100mV 1.2 k Ω
Parameter Description
Number 8
Configu ation
8 selectable for output override, remote job
selection
Input Voltage Protection
Diodes to supply and common. Source must
limit current to 10 mA for override conditions
Voltage Levels
<1.3V: Low
>3.7V: High (TTL)
5V maximum, 0V minimum
Maximum Switch Resistance to Pull Input Low 1 k Ω
Minimum Switch Off Resistance 11 k Ω
Update Rate 6 Hz
