High process alarm setpoint, High process alarm type, High process alarm output number – Watlow CLS200 User Manual
Page 116: Deviation alarm value
Chapter 4: Setup
CLS200 Series User’s Guide
100
Watlow Anafaze
Doc.# 0600-3050-2000
High Process Alarm Setpoint
Set the value at which the high process alarm activates.
Selectable values: Any point within the scaled sensor
range.
High Process Alarm Type
Select an alarm type for the high process alarm.
Selectable values: OFF, ALARM, or CONTROL.
High Process Alarm Output Number
Choose a digital output to activate when the high process
alarm occurs, if desired.
Selectable values: NONE, or any output from 1 to 34 not
enabled for closed-loop control or for the Serial DAC clock.
Deviation Alarm Value
Set the deviation from setpoint at which the high and low
deviation alarms occur.
Selectable values: 0 to 255, 25.5, 2.55, .255 or.0255,
depending on the INPUT TYPE and DISP FORMAT settings.
ALARM
01 HI PROC ALARM
SETPT ? 1000
ALARM
01 HI PROC ALARM
TYPE ? OFF
ALARM
01 HI PROC ALARM
OUTPUT? NONE
ALARM
01 DEV ALARM
VALUE ? 5
