Chapter 7: Ramp/Soak CLS200 Series User’s Guide
140 Watlow Anafaze Doc.# 0600-3050-2000
Edit Segment Number
Each profile is made up of several segments (up to 20).
Choose the segment to edit.
Selectable values: 1 to 20.
The first time you use this parameter, it defaults to seg-
ment 1. When you finish editing a segment, the controller
goes to the next segment. This loop continues until you
make a segment the last segment of a profile.
Segment Time
Enter the duration of the segment.
Selectable values: 0:00 to 999:59 (hours and minutes or
minutes and seconds, depending on the selected time base).
Segment Setpoint
Enter the ending setpoint for the segment you are editing.
For a ramp, the setpoint changes steadily over the segment
time from the end setpoint of the previous segment to the
value set here. For a soak, set the value here equal to the
end setpoint of the previous segment.
Selectable values: -999 to 3276, or OFF (no output dur-
ing segment). See Setpoints and Tolerances for Various In-
put Types on page 144.
ALARM
A EDIT SEGMENT
NUMBER? 15
ALARM
A SEGMENT 11
SEG TIME? 000:00
ALARM
C SEGMENT 5
SEG SETPT? OFF
