CLS200 Series User’s Guide Chapter 7: Ramp/Soak
Doc.# 0600-3050-2000 Watlow Anafaze 141
Edit Segment Events
You can assign up to four digital outputs, or events, to each
segment. When the segment ends, the outputs you select
are set to the state you specify. Press
YES to select outputs
and specify their states.
Press
NO to advance to the EDIT SEG TRGGRS parameter.
NOTE! Events are set at the end of segments. If you
want a segment to start with an event, pro-
gram the event in the previous segment. You
can also create a segment with zero time pre-
ceding the segment during which you want
the event on.
Segment Event Output
Select a digital output for the event. Use a digital output
that is not being used for PID control or for Serial DAC
clock.
This parameter appears only if you answered YES to EDIT
SEG EVENTS?
Selectable values: Any digital output from 1 to 34, except
those in use, or NONE (no event).
When you are done setting segment events, press
BACK to
return to EDIT SEG EVENTS, then press NO to go to the
next parameter.
Segment Events Output States
Assign a state to the event. At the end of the segment, the
output goes to the state you assign here.
This parameter appears only if you answered
YES to EDIT
SEG EVENTS?
Selectable values: OFF (high) or ON (low).
ALARM
A SEGMENT 5
EDIT SEG EVENTS?
ALARM
A SEG 20 EVENT 3
OUTPUT? 30
ALARM
A SEG20 EV3 DO 30
ACTIVE STATE? OFF
