CLS200 Series User’s Guide Chapter 4: Setup
Doc.# 0600-3050-2000 Watlow Anafaze 75
Load Setup From Job
NOTE! Current settings are overwritten when you
select a job from memory. Save your current
settings to another job number if you want to
keep them.
Load any one of eight jobs saved in battery-backed RAM.
Selectable values: 1 to 8
The following parameters are loaded for each loop as part
of a job:
• PID constants, filter settings, setpoints and spread
values.
• Loop control status (automatic or manual) and output
values (if the loop is in manual control)
• Alarm function (off, alarm control) setpoints, high/low
process setpoints, high/low deviation setpoints and
deadband settings, and loop alarm delay.
If you have enabled the remote job select function (see Job
Select Digital Inputs on page 76), you will not be able to
load a job. If you try, you will see this message:
Save Setup to Job
Save the job information for every loop to one of eight jobs
in the battery-backed RAM.
Selectable values: 1 to 8
If you have enabled the remote job select function (see Job
Select Digital Inputs on page 76), you will not be able to
save a job. If you try, you will see this message:
ALARM
LOAD SETUP
FROM JOB? 1
ALARM
CANNOT LOAD JOB
REMOTE SELECT ON
ALARM
SAVE SETUP
TO JOB? 1
ALARM
CANNOT SAVE JOB
REMOTE SELECT ON
