CLS200 Series User’s Guide Chapter 4: Setup
Doc.# 0600-3050-2000 Watlow Anafaze 101
High Deviation Alarm Type
Select an alarm type for the high deviation alarm.
Selectable values: ALARM, CONTROL or OFF
High Deviation Alarm Output Number
Choose a digital output to activate when the high deviation
alarm occurs, if desired.
Selectable values: NONE, or any output from 1 to 34 not
enabled for closed-loop control or for the Serial DAC clock.
Low Deviation Alarm Type
Select an alarm type for the low deviation alarm.
Selectable values: ALARM, CONTROL or OFF.
Low Deviation Alarm Output Number
Choose a digital output to activate when the low deviation
alarm occurs, if desired.
Selectable values: NONE, or any output from 1 to 34 not
enabled for closed-loop control or for the Serial DAC clock.
ALARM
01 HI DEV ALARM
TYPE ? OFF
ALARM
01 HI DEV ALARM
OUTPUT ? NONE
ALARM
01 LO DEV ALARM
TYPE ? OFF
ALARM
01 LO DEV ALARM
OUTPUT ? NONE
