Installation – Watlow CLS200 User Manual
Page 27
Doc.# 0600-3050-2000
Watlow Anafaze
11
2
Installation
This chapter describes how to install the CLS200 series
controller and its peripherals. Installation of the controller
involves the following procedures:
•
Determining the best location for the controller
•
Mounting the controller and TB50
•
Power connection
•
Input wiring
•
Communications wiring (EIA/TIA-232 or EIA/TIA-
485)
•
Output wiring
WARNING!
Risk of electric shock. Shut off power to your
entire process before you begin installation
of the controller.
WARNING!
The controller may fail in a 0% or 100% power
output state. To prevent death, personal inju-
ry, equipment damage or property damage,
install external safety shutdown devices. If
failure may cause death or injury, you must
install FM-approved safety shutdown devic-
es that operate independently from the pro-
cess control equipment.
