Chapter 7: Ramp/Soak CLS200 Series User’s Guide
136 Watlow Anafaze Doc.# 0600-3050-2000
Ramp/Soak Menus
The SETUP R/S PROFILES menu appears between the
SETUP LOOP ALARMS and MANUAL I/O TEST menus. Fig-
ure 7.2 shows the ramp/soak setup menu tree.
Figure 7.2 Setup Ramp/Soak Profiles Menu
ENTER
ENTER
SETUP
LOOP
INPUTS SETUP
LOOP CONTROL
PARAMETERS SETUP
LOOP
OUTPUTS SETUP
LOOP
ALARMS MANUAL
I/O
TEST
YES
SETUP
RAMP/SOAK
PROFILE
YES
YES
BACK
YES
BACK
YES
BACK
SETUP
LOOP PV
RETRANSMIT*
* See Process Variable Retransmit on page 113.
RAMP/SOAK TIME BASE
SETUP
GLOBAL
PARAMETERS
EDIT RAMP & SOAK
PROFILE?
COPY SETUP FROM
PROFILE?
OUT-OF-TOLRNCE
ALARM TIME?
READY SEGMENT
SETPOINT?
READY SEGMENT
EDIT EVENTS?
EXTERNAL RESET
INPUT NUMBER?
EDIT SEGMENT
NUMBER?
SEGMENT ##
SEG TIME?
SEGMENT ##
SEG SETPT?
SEGMENT ##
EDIT SEG EVENTS?
SEGMENT ##
EDIT SEG TRGGRS?
SEGMENT ##
SEG TOLERANCE?
SEGMENT ##
LAST SEGMENT?
REPEAT CYCLES?
READY EVENT
OUTPUT
SEG ## EVENT #
OUTPUT?
SEG ## TRIG #
INPUT NR?
SEG ## EV# DO##
ACTIVE STATE?
SEG ## TR# DI##
ACTIVE STATE?
SEG ## TR# DI##
TRIG?
