Chapter 8: Tuning and Control CLS200 Series User’s Guide
162 Watlow Anafaze Doc.# 0600-3050-2000
Table 8.4 General PID Constants
Application
Proportional
Band
Integral Derivative Filter
Output
Type
Cycle
Time
Action
Electrical heat
with solid state
relays
50
°
60 15 4 DZC - Reverse
Electrical heat
with electrome-
chanical relays
50
°
60 15 6 TP 20 Reverse
Cool with sole-
noid valve 70
°
500 90 4 TP 10 Direct
Cool with fans
10
°
Off 10 4 TP 10 Direct
Electric heat
with open heat
coils
30
°
20 Off 4 DZC - Reverse
Gas heat with
motorized
valves
Setpoint>1200
60
°
100
°
120
240
25
40
8 Analog - Reverse
