Extron Electronics SME 100 User Guide User Manual
Page 56

Live View Page Notifications
The following notifications may appear on the Live View page:
•
Starting a stream with the
Play icon or
Play
button displays the
initializing...
notification, unless the
Video Init Time
(sec)
0
.
•
Stopping a stream with the
Stop
button displays the
stream stopped
notification.
•
When a stream is disconnected, the
disconnected
notification is displayed.
•
When the video configuration settings of the stream are changed, the
Config Changed, refreshing...
notification is displayed.
•
When the SME 100 has reached its limit of connected users, a dialog box appears
containing the following message:
The maximum number of users has been
reached
.
SME 100 • Web-based User Interface Operation
50
