Available Input Video Signal Types
The
Input #N
submenu is used to select a video signal type for the currently selected input.
Each input supports different video signal types as shown in the table below.
Video Input 1
Video Input 2
Video Input 3
*
YUVp/HDTV
*
RGB
*
DVI
YUVi
YUVp/HDTV
S-Video
RGBcvS
Composite
YUVi
S-Video
Composite
Auto Detect
NOTE: * = Default video signal type
Selecting and Configuring an Input
Depending on the video signal type of the selected input, different adjustments are available
for the different inputs. The table below details which submenu adjustments are available for
each video signal type.
Input
Adjustment
RGB
YUVp /
HDTV
RGBcvS
YUVi
S-Video Composite
DVI
Film Detect
X
X
X
X
X
X
X
H Start
X
X
X
X
X
X
V Start
X
X
X
X
X
X
Total Pixels
X
X
Phase
X
X
H Active Pixels
X
X
X
X
X
X
V Active Lines
X
X
X
X
X
X
EDID
X
X
Use the following procedure to configure any of the three video inputs.
1.
Select an input from the front panel of the SME 100 (see item
b
in the "
2.
To configure the selected input, press the Menu button repeatedly until the
Input Config
primary configuration menu is shown on the LCD display.
3.
Press the Next button repeatedly until the desired submenu is shown on the LCD
display.
4.
Rotate either Adjust knob to configure the settings of the selected submenu
(see
on page 26 for information on using the Adjust knobs).
5.
After all adjustments have been completed, do one of the following to save the
configuration.
•
Press the Next button to display another submenu.
•
Press the Menu button repeatedly until the
Exit Menu? Press NEXT
menu
appears, then press the Next button to return to the default display cycle (see the
"
" section on page 18 to see the default display cycle).
•
Do nothing more and wait until the LCD display returns to the default display cycle
(approximately 30 seconds).
