Command
ASCII Command
(host to unit) Response
(unit to host)
Additional Description
Stream mode
Set stream mode
E X5@ SMOD } Smod X5@ ] Set the stream mode to X5@.
View stream mode E SMOD } X5@ ] View the currently set stream
mode.
Bit rate control
Set bit rate control
E X5# BRCT } Brct X5# ] Set the bit rate control to X5#.
View bit rate control E BRCT } X5# ] View the currently set bit rate
control.
Total stream bit rate max
Set maximum bit rate
value
E S X6( BITR } Bitr S X6( ] Set the maximum (total) bit rate
value to X6(.
View maximum bit
rate value E S BITR } X6( ] View the maximum (total) bit
rate allowed for streaming.
Video bit rate max
Set maximum bit rate
value
E M X5) BITR } Bitr M X5) ] Set the maximum (total) video
bit rate value to X5).
View maximum bit
rate value E M BITR } X5) ] View the maximum (total)
video bit rate allowed for each
stream.
Video bit rate target
Set target bit rate
E V X5$ BITR } Bitr V X5$ ] Set the target bit rate for
variable bit rate to X5$.
View target bit rate E V BITR } X5$ ] View the currently set target bit
rate for variable bit rate.
Group of pictures (GOP) length
Set GOP length
E X5* GOPL } Gopl X5* ] Set GOP length to X5*.
View GOP length E GOPL } X5* ] View the currently set GOP
length.
Pull Stream method
Set streaming
method
E X5( STRM } Strm X5( ] Set streaming method type to
X5(.
View streaming
method E STRM } X5( ] View the currently set
streaming method type.
Time to live (TTL) Pull Stream Multicast only
Set TTL
E X7) STTL } Sttl X7) ] Set the number of TTL hops.
View TTL E STTL } X7) ] View the currently set number
of TTL hops.
NOTES:
X5) = Maximum video bit rate (kbps) 200 through 10000 (default = 10000)
X5@ = Stream mode 0 = Audio and video (default), 1 = Video
X5# = Bit rate control 0 = Variable Bit Rate (VBR; default),
1 = Constrained Variable Bit Rate (CVBR), 2 = Constant Bit Rate (CBR)
X5$ = Target video bit rate (kbps) 200 through 10000 (default = 1000)
X5* = GOP length 1 through 30 (default = 30)
X5( = Streaming method 0 = Unicast RTP, 3 = Multicast RTP over UDP
X6( = Maximum stream bit rate (kbps) 5000 through 99000 (default = 80000)
X7) = Total time to live (hops) 1 through 255 (default = 10)
