Command

ASCII Command
(host to unit)

Response
(unit to host)

Additional Description

Output Configurations
Encoder profile type
Set encode profile

E X8) EPRO }

Epro X8) ]

Set encode profile to X8).

View encode profile

E EPRO }

X8) ]

View current encode profile.

Closed Caption
Set CC format

E X8@ TVCC }

Tvcc X8@ ]

Set CC to X8@.

View CC format

E TVCC }

X8@ ]

View current CC status.

Video resolution
Set resolution

E X2! VRES }

Vres X2! ]

Set the resolution to X2!.

View resolution

E VRES }

X2! ]

View the currently set
resolution.

Video frame rate
Set frame rate

E X5! VFRM }

Vfrm X5! ]

Set the frame rate value to X5!.

View frame rate

E VFRM }

X5! ]

View the currently set frame
rate.

Push stream control
Set push stream
control

E1

*

X8&STRC }

Strc1

*

X8& ]

Set stream control for push
stream X8&.

View push stream
control

E1STRC }

X8& ]

View stream control for push
stream X8& .

SAP session name
Write session name

E1,X1$ SNAM }

Snam1,X1$ ]

Set the SAP session name (X1$)
for push stream 1.

View session name

E1SNAM }

X1$ ]

View the SAP session name for
push stream 1.

NOTES:

To restore a default SAP Session Name, a single space character should be entered for ; unassigned
Session names = "[UnitName_Stream]" valid only for existing Session Names.

Session Names saved without a name will be saved with default "UnitName_OutputX" (

Example:

SME-100_Output01), standard character sets allowed.

NOTES:

X1$

= Text label / Preset name

up to 16 characters

X2!

= Encoder resolution

3 through 17 (see

Encoder resolution

on page 127)

X5!

= Video frame rate

1 through 30 (default = 30)

X8)

= Encode profile

1 = Base, 2 = Main, 3 = High

X8@

= Closed caption

0 =*Off/Disable, 1 = On/Enable

X8&

= Push stream control

0 =*Off/Disable, 1 = On/Enable

SME 100 • Remote Communication and Control

138
