Page 177
3.
Click on the
Browse
button and use the file browser to navigate to the location where
the firmware file was saved. Select the file and click
Open
.
ATTENTION: The extension of the firmware file must be .eff or .efs. Opening a file
with an incorrect extension may cause the SME 100 to stop functioning.
4.
Click the
Upload
button (located next to the
Browse
button). The Firmware Upgrade
page shows the progress of the installation and the LCD screen on the front panel of
the SME 100 says
Upgrading Firmware
while the firmware is being installed. The
firmware upgrade takes a few minutes to install.
5.
After the firmware is properly installed, the SME 100 reboots, initializes the upgraded
firmware, and starts to refresh the web-based user interface. The firmware installation is
complete when the Live View page is automatically loaded on the web browser.
SME 100 • Reference Information
171
