DS26519 16-Port T1/E1/J1 Transceiver
89 of 310
9.11 Power-Supply Decoupling
Table 9-37. Recommended Supply Decoupling
SUPPLY PINS DECOUPLING CAPACITANCE NOTES
DVDD33/DVSS 0.01
μF + 0.1μF + 1μF + 10μF
—
DVDD18/DVSS 0.01
μF + 0.1μF + 1μF + 10μF
—
ATVDD/ATVSS 0.1
μF (x16) + 1μF (x8) + 10μF (x4)
It is recommended to use one 0.1
μF cap for each
ATVDD/ATVSS pair (16 total), one 1
μF for every
two ATVDD/ATVSS pairs (8 total), and four 10
μF
capacitors for the analog transmit supply pins.
These capacitors should be located as close to the
intended power pins as possible.
ARVDD/ARVSS 0.1
μF (x16) + 1μF (x8) + 10μF (x4)
It is recommended to use one 0.1
μF cap for each
ARVDD/ARVSS pair (16 total), one 1
μF for every
two ARVDD/ARVSS pairs (8 total), and four 10
μF
capacitors for the analog receive supply pins.
These capacitors should be located as close to the
intended power pins as possible.
ACVDD/ACVSS 0.1
μF + 1μF + 10μF
—
