DS26519 16-Port T1/E1/J1 Transceiver
54 of 310
Table 9-10. RSYNCn Input Pin Definitions ( GTCR1 .GIBO = 0)
PIN NORMAL USE 4.096MHz IBO 8.192MHz IBO 16.384MHz IBO
RSYNC1
Receive Frame Pulse
for Port 1
Receive Frame Pulse
for Ports 1 and 2
Receive Frame Pulse
for Ports 1–4
Receive Frame Pulse
for Ports 1–8
RSYNC2
Receive Frame Pulse
for Port 2
Unused Unused Unused
RSYNC3
Receive Frame Pulse
for Port 3
Receive Frame Pulse
for Ports 3 and 4
Unused Unused
RSYNC4
Receive Frame Pulse
for Port 4
Unused Unused Unused
RSYNC5
Receive Frame Pulse
for Port 5
Receive Frame Pulse
for Ports 5 and 6
Receive Frame Pulse
for Ports 5–8
Unused
RSYNC6
Receive Frame Pulse
for Port 6
Unused Unused Unused
RSYNC7
Receive Frame Pulse
for Port 7
Receive Frame Pulse
for Ports 7 and 8
Unused Unused
RSYNC8
Receive Frame Pulse
for Port 8
Unused Unused Unused
RSYNC9
Receive Frame Pulse
for Port 9
Combined Receive
Frame Pulse for Ports
9 and 10
Combined Receive
Frame Pulse for Ports
9–12
Receive Frame Pulse
for Ports 9–16
RSYNC10
Receive Frame Pulse
for Port 10
Unused Unused Unused
RSYNC11
Receive Frame Pulse
for Port 11
Combined Receive
Frame Pulse for Ports
11 and 12
Unused Unused
RSYNC12
Receive Frame Pulse
for Port 12
Unused Unused Unused
RSYNC13
Receive Frame Pulse
for Port 13
Combined Receive
Frame Pulse for Ports
13 and 14
Combined Receive
Frame Pulse for Ports
13–16
Unused
RSYNC14
Receive Frame Pulse
for Port 14
Unused Unused Unused
RSYNC15
Receive Frame Pulse
for Port 15
Combined Receive
Frame Pulse for Ports
15 and 16
Unused Unused
RSYNC16
Receive Frame Pulse
for Port 16
Unused Unused Unused
