DS26519 16-Port T1/E1/J1 Transceiver

167 of 310

RDS0M

Receive DS0 Monitor Register

060h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16

Bit

# 7 6 5 4 3 2 1 0

Name

B1 B2 B3 B4 B5 B6 B7 B8

Default

0 0 0 0 0 0 0 0

Bits 7 to 0: Receive DS0 Channel Bits (B[1:8]). Receive channel data that has been selected by the Receive
Channel Monitor Select Register (

). B8 is the LSB of the DS0 channel (last bit to be received).
