DS26519 16-Port T1/E1/J1 Transceiver

278 of 310

11.3 E1 Receiver Functional Timing Diagrams

Figure 11-17. E1 Receive-Side Timing













FRAME#

1

2 3 4 5 6

7

8

9

10

11

12

13

14

15

16 1

RSYNCn

2

RSYNCn

1

RFSYNCn

NOTE 1: RSYNCn IN FRAME MODE (RIOCR.0 = 0).
NOTE 2: RSYNCn IN MULTIFRAME MODE (RIOCR.0 = 1).
NOTE 3: THIS DIAGRAM ASSUMES THE CAS MF BEGINS IN THE RAF FRAME.

Figure 11-18. E1 Receive-Side Boundary Timing (Elastic Store Disabled)




CHANNEL 32

CHANNEL 1

CHANNEL 2

CHANNEL 32

CHANNEL 1

CHANNEL 2

RCLKn

RSERn

RSYNCn

RFSYNCn

RSIGn

RCHCLKn

1

RCHBLKn

1

C

D

A

LSB

MSB

A

B

Si

1

A

Sa4 Sa5 Sa6 Sa7 Sa8

B

Note 3

NOTE 1: RCHBLKn IS PROGRAMMED TO BLOCK CHANNEL 1.
NOTE 2: SHOWN IS AN RNAF FRAME BOUNDARY.
NOTE 3. RSIGn NORMALLY CONTAINS THE CAS MULTIFRAME ALIGNMENT NIBBLE (0000) IN CHANNEL 1.
