DS26519 16-Port T1/E1/J1 Transceiver
51 of 310
Table 9-7. RSIGn Output Pin Definitions ( GTCR1 .GIBO = 0)
PIN NORMAL USE 4.096MHz IBO 8.192MHz IBO 16.384MHz IBO
RSIG1
Receive Signaling
Data for Port 1
Combined Receive
Signaling Data for
Ports 1 and 2
Combined Receive
Signaling Data for
Ports 1–4
Receive Signaling
Data for Ports 1–8
RSIG2
Receive Signaling
Data for Port 2
Unused Unused Unused
RSIG3
Receive Signaling
Data for Port 3
Combined Receive
Signaling Data for
Ports 3 and 4
Unused Unused
RSIG4
Receive Signaling
Data for Port 4
Unused Unused Unused
RSIG5
Receive Signaling
Data for Port 5
Combined Receive
Signaling Data for
Ports 5 and 6
Combined Receive
Signaling Data for
Ports 5–8
Unused
RSIG6
Receive Signaling
Data for Port 6
Unused Unused Unused
RSIG7
Receive Signaling
Data for Port 7
Combined Receive
Signaling Data for
Ports 7 and 8
Unused Unused
RSIG8
Receive Signaling
Data for Port 8
Unused Unused Unused
RSIG9
Receive Signaling
Data for Port 9
Combined Receive
Signaling Data for
Ports 9 and 10
Combined Receive
Signaling Data for
Ports 9–12
Receive Signaling
Data for Ports 9–16
RSIG10
Receive Signaling
Data for Port 10
Unused Unused Unused
RSIG11
Receive Signaling
Data for Port 11
Combined Receive
Signaling Data for
Ports 11 and 12
Unused Unused
RSIG12
Receive Signaling
Data for Port 12
Unused Unused Unused
RSIG13
Receive Signaling
Data for Port 13
Combined Receive
Signaling Data for
Ports 13 and 14
Combined Receive
Signaling Data for
Ports 13–16
Unused
RSIG14
Receive Signaling
Data for Port 14
Unused Unused Unused
RSIG15
Receive Signaling
Data for Port 15
Combined Receive
Signaling Data for
Ports 15 and 16
Unused Unused
RSIG16
Receive Signaling
Data for Port 16
Unused Unused Unused
