DS26519 16-Port T1/E1/J1 Transceiver
62 of 310
shows the registers that are related to setting up the framing.
Table 9-15. Registers Related to Setting Up the Framer
REGISTER
FRAMER 1
ADDRESSES
FUNCTION
Transmit Master Mode Register (
) 180h
T1/E1
mode.
Transmit Control Register 1 (
)
181h
Source of the F-bit.
Transmit Control Register 2 (
182h
F-bit corruption, selection of SLC-96.
Transmit Control Register 3 (
)
183h
ESF or D4 mode selection.
Receive Master Mode Register (
)
080h
T1/E1 selection for receiver.
Receive Control Register 1 (
081h
Resynchronization criteria for the framer.
Receive Control Register 2 (
014h
T1 remote alarm and OOF criteria.
Receive Control Register 2 (
)
082h
E1 receive loss of signal criteria selection.
Receive Latched Status Register 1 (
090h
Receive latched status 1.
Receive Interrupt Mask Register 1 (
0A0h
Receive interrupt mask 1.
Receive Latched Status Register 2 (
091h
Receive latched status 2.
Receive Interrupt Mask Register 2 (
0A1h
Receive interrupt mask 2.
Receive Latched Status Register 4 (
093h
Receive latched status 4.
Receive Interrupt Mask Register 4 (
0A3h
Receive interrupt mask 4.
Frames Out of Sync Count Register 1
(
054h
Framer out of sync register 1.
Frames Out of Sync Count Register 2
(
055h
Framer out of sync register 2.
E1 Receive Align Frame Register (
) 064h
RAF
byte.
E1 Receive Non-Align Frame Register
(
065h RNAF
byte.
Transmit SLC-96 Data Link Register 1
(
)
164h
Transmit SLC-96 bits.
Transmit SLC-96 Data Link Register 2
(
)
165h
Transmit SLC-96 bits.
Transmit SLC-96 Data Link Register 3
(
)
166h
Transmit SLC-96 bits.
Receive SLC-96 Data Link Register 1
(
064h
Receive SLC-96 bits.
Receive SLC-96 Data Link Register 2
(
065h
Receive SLC-96 bits.
Receive SLC-96 Data Link Register 3
(
066h
Receive SLC-96 bits.
Note: The addresses shown above are for Framer 1.
