DS26519 16-Port T1/E1/J1 Transceiver
53 of 310
Table 9-9. TSIGn Input Pin Definitions ( GTCR1 .GIBO = 0)
PIN NORMAL USE 4.096MHz IBO 8.192MHz IBO 16.384MHz IBO
TSIG1
Transmit Signaling
Data for Port 1
Combined Transmit
Signaling Data for
Ports 1 and 2
Combined Transmit
Signaling Data for
Ports 1–4
Transmit Signaling
Data for Ports 1–8
TSIG2
Transmit Signaling
Data for Port 2
Unused Unused Unused
TSIG3
Transmit Signaling
Data for Port 3
Combined Transmit
Signaling Data for
Ports 3 and 4
Unused Unused
TSIG4
Transmit Signaling
Data for Port 4
Unused Unused Unused
TSIG5
Transmit Signaling
Data for Port 5
Combined Transmit
Signaling Data for
Ports 5 and 6
Combined Transmit
Signaling Data for
Ports 5–8
Unused
TSIG6
Transmit Signaling
Data for Port 6
Unused Unused Unused
TSIG7
Transmit Signaling
Data for Port 7
Combined Transmit
Signaling Data for
Ports 7 and 8
Unused Unused
TSIG8
Transmit Signaling
Data for Port 8
Unused Unused Unused
TSIG9
Transmit Signaling
Data for Port 9
Combined Transmit
Signaling Data for
Ports 9 and 10
Combined Transmit
Signaling Data for
Ports 9–12
Transmit Signaling
Data for Ports 9–16
TSIG10
Transmit Signaling
Data for Port 10
Unused Unused Unused
TSIG11
Transmit Signaling
Data for Port 11
Combined Transmit
Signaling Data for
Ports 11 and 12
Unused Unused
TSIG12
Transmit Signaling
Data for Port 12
Unused Unused Unused
TSIG13
Transmit Signaling
Data for Port 13
Combined Transmit
Signaling Data for
Ports 13 and 14
Combined Transmit
Signaling Data for
Ports 13–16
Unused
TSIG14
Transmit Signaling
Data for Port 14
Unused Unused Unused
TSIG15
Transmit Signaling
Data for Port 15
Combined Transmit
Signaling Data for
Ports 15 and 16
Unused Unused
TSIG16
Transmit Signaling
Data for Port 16
Unused Unused Unused
