DS26519 16-Port T1/E1/J1 Transceiver

23 of 310

NAME PIN

TYPE

FUNCTION

TSYNC1/

TSSYNCIO1

F8

TSYNC2/

TSSYNCIO2

D13

TSYNC3/

TSSYNCIO3

R9

TSYNC4/

TSSYNCIO4

AB3

TSYNC5/

TSSYNCIO5

AA7

TSYNC6/

TSSYNCIO6

AA9

TSYNC7/

TSSYNCIO7

D20

TSYNC8/

TSSYNCIO8

H16

TSYNC9/

TSSYNCIO9

K15

TSYNC10/

TSSYNCIO10

N16

TSYNC11/

TSSYNCIO11

Y6

TSYNC12/

TSSYNCIO12

M8

TSYNC13/

TSSYNCIO13

M7

TSYNC14/

TSSYNCIO14

K5

TSYNC15/

TSSYNCIO15

D19

TSYNC16/

TSSYNCIO16

G16

Input/

Output

Transmit Synchronization 1 to 16.

A pulse at these pins establishes either

frame or multiframe boundaries for the transmit side. These signals can also be
programmed to output either a frame or multiframe pulse. If these pins are set to
output pulses at frame boundaries, they can also be set to output double-wide
pulses at signaling frames in T1 mode. The operation of these signals is
synchronous with TCLK[1:16] These pins are selected when the transmit elastic
store is disabled.

Transmit System Synchronization In.

These pins are selected when the

transmit-side elastic store is enabled. A pulse at these pins establishes either
frame or multiframe boundaries for the transmit side. Note that if the elastic store
is enabled, frame or multiframe boundary is established for the transmitters.
Should be tied low in applications that do not use the transmit-side elastic store.
The operation of this signal is synchronous with TSYSCLK[1:16].

Transmit System Synchronization Out.

If configured as an output and the

transmit elastic store is enabled, an 8kHz pulse synchronous to BPCLK1 for
TSSYNCIO[1:8] BPCLK2 for TSSYNCIO[9:16] will be generated. This pulse in
combination with BPCLK[1:2] can be used as an IBO master. TSSYNCIOn can
be used as a source to RSYNCn and TSSYNCIOn of another DS26519 or
RSYNC and TSSYNC of other Dallas Semiconductor parts.

TSIG1 B14
TSIG2 C14
TSIG3 P9
TSIG4 R11
TSIG5 T12
TSIG6 U12
TSIG7 B17
TSIG8 F14
TSIG9 U22

TSIG10 V21
TSIG11 U6
TSIG12 A1
TSIG13 F1
TSIG14 H2
TSIG15 G14
TSIG16 G17

Input

Transmit Signaling 1 to 16.

When enabled, this input samples signaling bits for

insertion into outgoing PCM data stream. Sampled on the falling edge of TCLKn
when the transmit-side elastic store is disabled. Sampled on the falling edge of
TSYSCLKn when the transmit-side elastic store is enabled. In IBO mode, the
TSIGn streams can run up to 16.384MHz. See

Table 9-9

.
