DS26519 16-Port T1/E1/J1 Transceiver
240 of 310
Register Name: TLS2
Register Description: Transmit Latched Status Register 2 (HDLC)
Register Address: 191h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name — — — TFDLE TUDR TMEND TLWMS TNFS
— — — — TUDR TMEND TLWMS TNFS
Default 0 0 0 0 0 0 0 0
Note: All bits in this register are latched and can create interrupts.
Bit 4: Transmit FDL Register Empty (TFDLE) (T1 Mode Only). Set when the TFDL register has shifted out all 8
bits. Useful if the user wants to manually use the TFDL register to send messages, instead of using the HDLC or
BOC controller circuits.
Bit 3: Transmit FIFO Underrun Event (TUDR). Set when the transmit FIFO empties out without having seen the
TMEND bit set. An abort is automatically sent.
Bit 2: Transmit Message End Event (TMEND). Set when the transmit HDLC controller has finished sending a
message.
Bit 1: Transmit FIFO Below Low Watermark Set Condition (TLWMS). Set when the transmit 64-byte FIFO
empties beyond the low watermark as defined by the transmit low watermark bits (TLWM), rising edge detect of
TLWM.
Bit 0: Transmit FIFO Not Full Set Condition (TNFS). Set when the transmit 64-byte FIFO has at least one empty
byte available for write. Rising edge detect of TNF. Indicates change of state from full to not full.
Register Name: TLS3
Register Description: Transmit Latched Status Register 3 (Synchronizer)
Register Address: 192h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name — — — — — — LOF LOFD
Default 0 0 0 0 0 0 0 0
Note: Some bits in this register are latched and can create interrupts.
Bit 1: Loss of Frame (LOF). A real-time bit that indicates that the transmit synchronizer is searching for the sync
pattern in the incoming data stream.
Bit 0: Loss Of Frame Synchronization Detect (LOFD). This latched bit is set when the transmit synchronizer is
searching for the sync pattern in the incoming data stream.
