DS26519 16-Port T1/E1/J1 Transceiver
174 of 310
Register Name: E1RSa6 (E1 Mode Only)
Register Description: Received Sa6 Bits Register
Register Address: 06Bh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name RSa6F15 RSa6F13 RSa6F11 RSa6F9 RSa6F7 RSa6F5 RSa6F3 RSa6F1
Default 0 0 0 0 0 0 0 0
Bit 7: Sa6 Bit of Frame 15 (RSa6F15)
Bit 6: Sa6 Bit of Frame 13 (RSa6F13)
Bit 5: Sa6 Bit of Frame 11 (RSa6F11)
Bit 4: Sa6 Bit of Frame 9 (RSa6F9)
Bit 3: Sa6 Bit of Frame 7 (RSa6F7)
Bit 2: Sa6 Bit of Frame 5 (RSa6F5)
Bit 1: Sa6 Bit of Frame 3 (RSa6F3)
Bit 0: Sa6 Bit of Frame 1 (RSa6F1)
Register Name: E1RSa7 (E1 Mode Only)
Register Description: Received Sa7 Bits Register
Register Address: 06Ch + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name RSa7F15 RSa7F13 RSa7F11 RSa7F9 RSa7F7 RSa7F5 RSa7F3 RSa7F1
Default
0 0 0 0 0 0 0 0
Bit 7: Sa7 Bit of Frame 15 (RSa4F15)
Bit 6: Sa7 Bit of Frame 13 (RSa7F13)
Bit 5: Sa7 Bit of Frame 11 (RSa7F11)
Bit 4: Sa7 Bit of Frame 9 (RSa7F9)
Bit 3: Sa7 Bit of Frame 7 (RSa7F7)
Bit 2: Sa7 Bit of Frame 5 (RSa7F5)
Bit 1: Sa7 Bit of Frame 3 (RSa7F3)
Bit 0: Sa7 Bit of Frame 1 (RSa7F1)
